Order(MOQ) :
1Payment :
50% Advance Payment , Balance Before DeliveryProduct Origin :
Bozhou City, Anhui Province ,ChinaColor :
CustomizableShipping Port :
Shanghai Or Qingdao, ChinaLead Time :
20-30 days after we receive 50% advance paymentFeatures:
*Using advanced method of fetching force, it maintains the power source of drum,and makes concrete keep concrete a good uniformity, without deposition and segreation.
*Scientific blade design maintains quick deischarging and low discharge residual percentage.
*Double-sidecontrol platform is free from limitation of working floor,with convenient operation. And there is no impact on highway condition when carrying out field opertion,requirements of narrow highways can be met.
Building Construction Concrete Mixer
Product Parameters
Overall Dimensions | 9780mm*2496mm*3990mm(L*W*H) |
Tare Weight | 13950kg |
Payload | 35000kg |
Front Overhang | 1500mm |
Rear Overhang | 2880mm |
Wheelbase | 4000mm+1400mm |
Track (F/R) | 2022mm/1830mm |
Chassis Brand | SINOTRUK HOWO |
Chassis Model | ZZ1257N4048W, driving type 6x4 |
Cab | HW76, left hand drive, air-conditioner, one sleeper |
Engine | SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L |
Transmission | HW19710, No. of speeds: 10 forward 2 reverse |
Steering | German ZF8098, turning system pressure 18MPa |
Rear Axle | HC16 tandem axle, rated load 2x13ton, ratio 5.73 |
Wheels and tires | Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel |
Brakes | Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake |
